Reference A/D D/A Converter USB
Ergens anders goedkoper? Geen probleem. Klik op ONDERHANDEL en we zullen een lagere prijs bieden !!
Heb je hulp nodig? Neem contact met ons op Laat feedback achter
Categories: Lynx Studio Technology, USB Audio
Product description
Two-channel 24-bit / 192 kHz Analog I/O, Headphone Amplifier Flexible monitor controller
ANALOG INPUTS
2 Balanced XLR connections with 8 trim level settings
ANALOG OUTPUTS
2 Balanced XLR connections with 8 trim level settings
2 Balanced TRS connections Monitor Out
Headphone TRS connection
DIGITAL INPUTS & OUTPUTS
AES/EBU: Transformer-coupled XLR connector
S/PDIF via Coaxial or Optical connector
ADAT via Optical Connector (8 channels at 48 kHz)
Computer connectivity via LT-USB (USB 2.0), LT-TB3 or LT-DANTE
LCD High-contrast, high-brightness IPS 480×272 pixel backlit touchscreen for set up, montoring, metering, diagnostics and future features
Allows setting of all sample rates, sync settings, signal routing, meter options and future functions
Standard bar graph metering of all inputs and outputs, large meters selectable for any input or output, VU style meters
Stereo 30-band Real Time Spectrum Analyzer (RTA) screen
Updatable FPGA allows addition of future features
FEATURES All standard sample rates from 44.1 kHz to 192 kHz
Line Out, Monitor out, and Headphone output have their own dedicated D/A converters and independent input selection
LSlot expansion slot for LT-USB (USB 2.0), LT-TB3 or LT-DANTE and future connectivity options
Onboard low-latency 32-channel digital mixer provides flexible I/O routing
English, Spanish, French, German and Chinese menus
SynchroLock 2 word clock for stable word clock, maximum jitter rejection, 7 ppm accuracy
OTHER Dual Power Option. 110 to 230 V AC or 9 to 18 V DC via battery pack or auto outlet
Sample Rate Conversion
DSD Record and Playback
Multipurpose rotary control on front panel
Computer connectivity via built in LT-USB (USB 2.0), LT-TB3 (Thunderbolt), or LT-DANTE (Dante) card
Measures 8.50 x 3.25 x 10.00 inches (half rack), weighs 6.75 pounds
LINE IN THD+N -116dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 122 dB, A-weighted, -60dBFS signal method
Frequency Resp. ± 0.01 dB, 20Hz 20kHz
Crosstalk -140 dB maximum @ 1kHz, -1dBFS signal
LINE OUT THD+N -116dB @1kHz, -1dBFS, 20kHz filter
Dynamic Range 122 dB, A- weighted, -60dBFS signal method
Frequency Resp. ± 0.02 dB, 20Hz 20kHz
Crosstalk -135 dB maximum @ 1kHz, -1dBFS signal
